Удобност
Подобрен поглед на возачот
Безбедност
Работна ефикасност
Енергетска ефикасност
Одржливост
Model | CPD10 | CPD15 | CPD18 | |
Configuration number | GC1/GC2(P) | GC1/GC2(P) | GC1/GC2(P) | |
Rated capacity | kg | 1000 | 1500 | 1750 |
Load center distance | mm | 500 | 500 | 500 |
Power mode | Battery | Battery | Battery | |
Driving mode | Seated | Seated | Seated | |
Wheel base | mm | 1380 | 1380 | 1380 |
Tyretype | Pneumatic | SE/Pneumatic | SE/Pneumatic | |
Front overhang | mm | 390 | 390 | 390 |
Mast tilt angle ,front/rear | 0 | 618 | 618 | 6/8 |
Height with mast retraction | mm | 1985 | 1985 | 1985 |
Free lifting height | mm | 155 | 155 | 155 |
Max. lifting height | mm | 3000 | 3000 | 3000 |
Max.height under working condition | mm | 4030 | 4030 | 4030 |
Overhead guard height | mm | 2130 | 2130 | 2130 |
Fork size:thicknessxwidth xlength | mm | 32x100x770 | 35x100x920 | 35x100x920 |
Fork arm carrier, DIN standard | 2A | 2A | 2A | |
Truck body length (fork excluded) | mm | 2070 | 2070 | 2070 |
Truck body width | mm | 1086 | 1086 | 1086 |
Turning radius | mm | 1750 | 1750 | 1750 |
Battery voltage/capacity Ks | V/Ah | 48/400(max600) | 48/400(max600) | 48/400(max600) |
